PXI530x - Bit-Pattern Receiver

Main features

  • Based on VX Instruments FlexCPP for easy custom design
  • Up to 2 independent modules with 4 simultaneously working channels
  • 6.6MS/s with 7Bit pattern width
  • High configurable trigger engine
  • Multiple instrument and channel synchronization possibilities
  • Additional reference clock output
  • Wide range of sample rates due to programmable internal PLL
Clear
Price request Datasheet

Flexible configurable PXI Platform
This family of bit-pattern generators is based on the “Flexible Configurable PXI Platform” (FlexCPP). This platform allows a couple of customer configured bit-pattern generators.

Bit-pattern receiver
The PXI530x Bit-Pattern Receiver family features up to 8 simultaneously working channels divided into 2 modules with 4 channels. Every channel provides a 8Bit TTL digital input. Each module is equipped with an on-board memory where the acquired bit-pattern from its 4 channels is stored.

Sample clock
The sample clock of every PXI530x receiver channel is derived from its input port signal Px. 7. In addition with a post divider for a integer division of the clock source signal the user gets a high flexibility in data acquisition.

Digital input
Every channel of the PXI530x Bit-Pattern Receiver is equipped with an 8Bit digital bus driver. So digital input signals compliant to TTL standard are provided to the user. All digital input ports are referenced to a common ground.

User specific daughter board
The PXI530x Bit-Pattern Receiver devices feature a connector interface to a user specific daughter board. For fixture of the board various mounting studs are available. So the whole placement area of the right adjacent slot within a PXI chassis is provided to the user.

In addition to the digital outputs and the reference clock signal the connector interface contains two supply voltages (+3.3V and +12V) with their according common ground. This features the user a solid base for his circuit design.

PXI5308 - 8 channel Bit-Pattern Receiver

Digital Input

PXI5304 - 4 channel Bit-Pattern Receiver

Digital Input

PXI530xBit-Pattern Receiver
PXI53088 channel Bit-Pattern Receiver
PXI53044 channel Bit-Pattern Receiver
