2120 - DC - 100KHz Linear high power amplifier

Main features

  • Over 22,000 watts peak for 40 mSec and 8,000 watts peak continuous into a 0.5-ohm load.
  • 40 mSec pulses of up to 209 amperes peak into a 0.5-ohm load.
  • System output of over 650 volts and 250 amperes maximum are possible with multiple, interconnected amplifiers.
  • Frequency bandwidth of DC to 50 kHz at rated power, DC to 100 kHz at reduced power.
  • Rugged chassis for stand-alone or rack mounted operation. No additional power supplies are required.
  • Protection circuitry protects the 2120 from input overloads, improper output connection
  • Shipped ready to operate from 208-volt (±10%) three-phase AC mains. Operation from 400-volt (±10%) AC mains are available on request.
Price request Datasheet

The AE Techron 2120 amplifier is a high-powered, DC-enabled unit designed to provide clean, reliable power for gradient coils in magnetic resonance imaging systems or in applications that require both significant short-term (burst) and long-term (continuous) power. A single 2120 has an output capability of over 210 amperes peak at its rated voltage. If more current is needed, up to four amplifiers can be combined in parallel and operate as a single system.

The 2120 can operate in either voltage or current mode and features robust output devices and a power range of over 6600 watts RMS. It provides very low noise and fast slew rates, and can safely drive a wide range of resistive, inductive loads..
