PC104P-24DSI12 - 12-Channel 24-Bit Delta-Sigma PC104+Board

Main features

  • 12 Differential 24-Bit Analog Input Channels
  • Delta-Sigma Converter per Channel, with Linear Phase Digital Antialias Filtering
  • Sample rates from 2 KSPS to 200 KSPS per Channel
  • Software-Selectable Input Ranges: ±2.5V, ±5V, ±10V
  • 256 K-sample FIFO Buffer
  • Synchronous or Independent ADC Clocking
  • Internal Sample Rate Generators
  • Hardware Sync and Clock I/O for Multiboard Synchronization
  • Low Phase Skew; Typically Less than 55ns with Fsig < 0.35*Fsamp
  • DMA Engine Supports both Block-Mode and Demand-Mode Transfers
  • Low Power Consumption. 6 Watts Typical. Only +5VDC Required from PCI bus.
  • 100dB Dynamic Range to 100KSPS; 93 dB SINAD
  • Exist in PCIe, PCI, cPCI/PXI, PC104 and PMC
Price request Datasheet

Low noise, 24-bit resolution, low phase distortion and multi-board synchronization make the PC104P-24DSI12 board ideal for state-of-the-art sonar and noise monitoring applications. The 12-channel 24DSI12 analog input board provides a high-density 24-bit analog input resources on a several expansion board. Optimized for flexibility and performance, the board is ideal for a wide variety of applications, ranging from simple precision voltage measurements, to the analysis of complex audio signals and waveforms.

Each of the 12 delta-sigma analog input channels can be controlled by any one of two independent sample clocks, and multiple channels can be harmonically locked together. A/D conversions on multiple boards can be synchronized and phase-locked. Input bandwidth is from DC to 80kHz. Sample rates are adjustable from 2KSPS to 200KSPS, and the input range is software selectable as ±2.5V, ±5V or ±10V. Internal autocalibration networks permit periodic calibration to be performed without removing the board from the system.
